Descrizione
Dati Tecnici
| Caratteristica | Valore |
|---|---|
| Sistema frenante | AKEBONO |
| Lato montaggio | Assale posteriore |
| Altezza [mm] | 40,2 |
| Lunghezza [mm] | 98,6 |
| Spessore [mm] | 15,1 |
| Nr. WVA | 25258 |
| Nr. WVA | 25259 |
| Nr. WVA | 25260 |
Codici Originali (OE)
La tabella elenca i codici OE associati ai modelli di auto compatibili.
| Produttore | Codici OE |
|---|---|
| SUZUKI | 55800-52R00, 55800-52R01, 55800-61M00, 55800-61M00-000, 55800-61M01, 55800-61M02, 55800-61M10, 55800-68L00, 55800-68L10, 55800-68L20, 55800-68L21, 55800-68R00, 55800-68R10, 55910-M68P00, 55910-M68P00-000, 55910-M68P01, 55910-M68P01-000 |
Compatibilià
| Produttore | Modello |
|---|---|
| SUZUKI | SWIFT IV (FZ, NZ) 1.2 (AZH 412, ZC72S) 10.2010, SWIFT IV (FZ, NZ) 1.2 (AZG 412, ZC72S) 10.2010, SWIFT IV (FZ, NZ) 1.2 4x4 (AZH 412, ZD72S) 10.2010, SWIFT IV (FZ, NZ) 1.2 4x4 (AZG 412, ZD72S) 10.2010, SWIFT IV (FZ, NZ) 1.3 DDiS (AZG 413D, ZC02S, ZC92S) 10.2010, SWIFT IV (FZ, NZ) 1.6 (AZG 416, AZH 416, RS416, ZC32S, ZA32S) 01.2012 |
| SUZUKI | VITARA (LY) 1.4 T (APK 414) 09.2015, VITARA (LY) 1.4 T AllGrip (APK 414) 09.2015, VITARA (LY) 1.6 (APK 416) 02.2015, VITARA (LY) 1.6 AllGrip (APK 416) 02.2015, VITARA (LY) 1.6 DDiS (APK 416D) 02.2015, VITARA (LY) 1.6 DDiS AllGrip (APK 416D) 02.2015, VITARA (LY) 1.0 (APK 310) 10.2018, VITARA (LY) 1.0 AllGrip (APK 310) 10.2018 |
| SUZUKI | SX4 S-CROSS (JY) 1.6 (AKK 416) 08.2013, SX4 S-CROSS (JY) 1.6 AllGrip (AKK 416) 08.2013, SX4 S-CROSS (JY) 1.6 DDiS (AKK 416D) 08.2013, SX4 S-CROSS (JY) 1.6 DDiS AllGrip (AKK 416D) 08.2013, SX4 S-CROSS (JY) 1.0 AllGrip (AKK 310) 08.2016, SX4 S-CROSS (JY) 1.0 (AKK 310) 08.2016, SX4 S-CROSS (JY) 1.4 T AllGrip (AKK 414) 08.2016, SX4 S-CROSS (JY) 1.4 T (AKK 414) 08.2016 |
| SUZUKI | BALENO (FW, EW) 1.0 (A1K310) 02.2016, BALENO (FW, EW) 1.2 (A1K412) 02.2016, BALENO (FW, EW) 1.2 Hybrid (A1K412) 02.2016 |
| SUZUKI | SWIFT V (AZ) 1.0 (A2L310) 04.2017, SWIFT V (AZ) 1.0 SHVS (A2L310) 04.2017, SWIFT V (AZ) 1.2 (A2L412) 04.2017, SWIFT V (AZ) 1.2 AllGrip (A2L412) 04.2017, SWIFT V (AZ) 1.2 SHVS (A2L412) 04.2017, SWIFT V (AZ) 1.2 SHVS AllGrip (A2L412) 04.2017, SWIFT V (AZ) 1.4 Sport (A2L414, ZC33S) 09.2017 |
